Premium Copper Bonded Plate – High-Performance IS 3043 Earthing
Product Overview
The Copper Bonded Plate is a durable and efficient earthing electrode designed to provide low-resistance grounding and long-term performance. It consists of a mild steel core bonded with a thick layer of high-conductivity copper, ensuring the perfect combination of mechanical strength and corrosion resistance.
This plate is widely used in industrial, commercial, and residential earthing systems, especially where stable grounding and extended service life are required.
These plates are widely used in earthing systems as per guidelines from Bureau of Indian Standards under IS 3043, ensuring safety and reliability in electrical installations.
Key Features
- Molecular Copper Bonding – Strong, uniform bonding for long life
- High Conductivity – Efficient fault current dissipation
- Corrosion Resistant – Ideal for underground installation
- High Mechanical Strength – Steel core ensures durability
- IS 3043 Compliant – Meets Indian earthing standards
- Low Maintenance – Reliable long-term performance
Applications
- Electrical grounding systems
- Industrial plants and factories
- Residential and commercial buildings
- Substations and transformers
- Lightning protection systems
Technical Specifications
| Material | Copper Bonded Steel |
|---|---|
| Size | 300×300 mm / 600×600 mm (Custom Available) |
| Thickness | 3 mm / 6 mm |
| Copper Coating | 100–250 Microns |
| Type | Plate Earthing Electrode |
| Standard | IS 3043 |
| Application | Earthing & Grounding Systems |
How it Works
The plate is installed in an earthing pit filled with conductive material. The copper bonded surface ensures low resistance contact with soil, while the steel core provides strength, allowing safe discharge of fault current and lightning energy.
Copper Bonded Plate vs GI Earthing Plate
| Feature | Copper Bonded Plate | GI Plate |
|---|---|---|
| Conductivity | High | Moderate |
| Corrosion Resistance | Excellent | Good |
| Lifespan | Long | Medium |
| Cost | Moderate | Lower |
Benefits of Copper Bonded Plate
This offers several advantages compared to conventional earthing plates:
- Provides stable and low resistance grounding
- More durable than GI plates
- Cost-effective compared to pure copper plates
- Performs well in corrosive and high resistivity soils
- Ensures long-term electrical safety
Why Choose Our Copper Bonded Plate?
Our product is manufactured using advanced bonding technology to ensure uniform copper coating and superior performance. Each plate is tested to meet strict quality standards.
- Manufacturer-direct pricing
- Bulk orders available
- Custom sizes and thickness options
- Fast delivery across India
